Specifications TC-H3 3MP Outdoor WiFi Kamera | |
|---|---|
| Model | Spec: I5W/ C/ WIFI/ Am/ 4mm/ V4.2 |
| Camera | |
| Image Sensor | 1/2.9″CMOS |
| Min. Illumination | Color: 0.02Lux@ (F1.6,AGC ON), B/W: 0Lux with IR |
| Shutter Time | 1s-1/100000s |
| Day&Night | IR-cut filter with auto switch (ICR) |
| WDR | DWDR |
| S/N | >38dB |
| Angle Adjustment | pan 0-294°; tilt 0-90° |
| Lens | |
| Lens Type | Fixed |
| Focal Length | 4mm |
| Lens Mount | M12 |
| Aperture Range | F1.6,Fixed |
| Field of View | 81.6°(H);43.1°(V);94.2°(D) |
| DORI Distance | Detect:57.14m Observe:22.68m Recognize:11.43m Identify:5.71m |
| Illuminator | |
| IR LEDs | 6 |
| IR Distance | 50m |
| Wavelength | 850nm |
| Compression Standard | |
| Video Compression | S+265/ H.265/ H.264B/ H.264M/ H.264H |
| Video Bit Rate | 32k-4M |
| Audio Compression | G.711A/G.711U |
| Audio Sampling Rate | 8kHz/16kHz |
| Image | |
| Max. Resolution | 2304×1296 @20fps |
| Main Stream | PAL: 20fps (2304×1296, 1920×1080, 1280×720, 704×576, 640×480) NTSC: 20fps (2304×129, 1920×1080, 1280×720, 704×480, 640×480) |
| Sub Stream | PAL: 20fps (704×576, 704×288, 352×288, 640×360) NTSC: 20fps (704×480, 704×240, 352×240, 640×360) |
| Third Stream | N/A |
| BLC | Yes |
| HLC | Yes |
| AGC | Yes |
| 3D DNR | Yes |
| White Balance | Auto/ Semi-auto/ Manual/ Sunny/ Natural light/ Warm light/ Sodium lamp/ Incandescent lamp/ Locked white balance |
| ROI | N/A |
| Corridor mode | N/A |
| EIS | N/A |
| OSD | 1region; 16*16/ 32*32 |
| Picture Overlay | N/A |
| Privacy Mask | 4 regions |
| Defog | Yes |
| Feature | |
| Alarm Trigger | Disk Full; Disk R/W Error; IP Address Conflict |
| Linkage Method | trigger sound; trigger warmlight; trigger recording; trigger capture; notify surveillance center |
| Early Warning(EW) | Yes |
| Auto-Tracking | Auto-Tracking |
| Network | |
| ANR | ANR |
| Protocols | HTTP; TCP/ IP; UDP; ICMP; DHCP; DNS; NTP; IPv4; SSH; Unicast; RTSP; FTP |
| System Compatibility | Onvif Profile S/T/G; CGI; MIL STONE |
| Remote Connection | ≤2 |
| Client | Easy7 Smart Client |
| Moblie Client | EasyLive Plus |
| Web | IE10+; Firefox52+; Edge89+; Safari11+; Chrome57+ |
| WIFI | |
| Transmission distance | Up tp 30m (The performance varies based on actual environment) |
| Wireless standard | IEEE 802.11b/ 802.11g/ 802.11n |
| Frequency range | 2.4 GHz ~ 2.4835 GHz |
| Interface | |
| Communication Interface | 1 RJ45 10M/ 100M self adaptive Ethernet port |
| Audio I/O | N/A |
| Alarm I/O | N/A |
| Built-In Mic | Yes |
| Built-In Speaker | Yes |
| Reset Button | Yes |
| On-board storage | Built-in Micro SD card slot, up to 512GB |
| General | |
| Web Client Language | 3 languages: Simple Chinese/ English/ Vietnamese |
| Operating Temperature | -30℃ – 60℃ |
| Operating Humidity | 0-95% |
| Storage Temperature | -30℃ – 60℃ |
| Storage Humidity | 0-95% (non-condensing) |
| Power Supply | DC 12V ±25%, MAX 12W |
| Protection | Surge protection 2000V; Lightning proof 6000V; IP66 |
| Boundary Dimensions | 138(L) 112(W) 173(H)mm |
| Package Dimensions | 155(L) 155(W) 195(H)mm |
| GrossWeight | 0.67 kg |
| NetWeight | 0.47 kg |
