| Motion Detection | |
|---|---|
| Motion Detection 2.0 | Deep learning-based motion detection enabled by default for all analog channels |
| Human / Vehicle Analysis | Classifies human and vehicle and reduces false alarms caused by objects such as leaves and lights |
| Quick Search | Search by object or event type supported |
| Video and Audio | |
| IP Video Input | 2-ch (up to 10-ch), up to 5 MP resolution |
| Supported IP Camera Compression | H.265+ / H.265 / H.264+ / H.264 |
| Analog Video Input | 8-ch, BNC interface (1.0 Vp-p, 75 Ω), supporting coaxitron connection |
| HDTVI Input | 1080p25, 1080p30, 720p25, 720p30 |
| AHD Input | 1080p25, 1080p30, 720p25, 720p30 |
| HDCVI Input | 1080p25, 1080p30, 720p25, 720p30 |
| CVBS Input | Support |
| HDMI Output | 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
| VGA Output | 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz |
| Video Output Mode | HDMI / VGA simultaneous output |
| Audio Input | 1-ch RCA (2.0 Vp-p, 1 KΩ), 8-ch via coaxial cable |
| Audio Output | 1-ch RCA (Linear, 1 KΩ) |
| Two-Way Audio | Reuse the first audio input |
| Synchronous Playback | 8-ch |
| Recording | |
| Video Compression | H.265 Pro+ / H.265 Pro / H.265 / H.264+ / H.264 |
| Encoding Resolution | 1080p Lite / 720p Lite / WD1 / 4CIF / VGA / CIF |
| Frame Rate | 1080p Lite / 720p Lite / WD1 / 4CIF / VGA / CIF @15 fps SD Stream: WD1 / 4CIF / VGA / CIF @25 fps (PAL) / 30 fps (NTSC) |
| Sub Stream | 1080p & 720p: CIF / QVGA @15 fps SD: CIF / QVGA @25 fps (PAL) / 30 fps (NTSC) |
| Video Bitrate | 32 Kbps – 4 Mbps |
| Stream Type | Video, Video & Audio |
| Audio Compression | G.711u |
| Audio Bitrate | 64 Kbps |
| Network | |
| Total Bandwidth | 72 Mbps |
| Remote Connection | 64 users |
| Network Protocol | TCP/IP, PPPoE, DHCP, HiLookVision, DNS, DDNS, NTP, SADP, SMTP, UPnP™, HTTPS |
| Network Interface | 1 × RJ45 10/100 Mbps self-adaptive Ethernet interface |
| Auxiliary Interface | |
| SATA | 1 SATA interface |
| HDD Capacity | Up to 4 TB |
| USB Interface | 2 × USB 2.0 |
| Alarm In/Out | N/A |
| General | |
| Power Supply | 12 VDC, 1.5 A |
| Power Consumption | ≤ 10 W (without HDD) |
| Working Temperature | -10 °C to 55 °C |
| Working Humidity | 10% – 90% |
| Dimensions | 263 × 225 × 48 mm |
| Weight | ≤ 1 kg (without HDD) |
