- General
- Core Color1 Blue & White/ Blue 2 Orange & White/ Orange,3 Green & White/ Green 4 Brown & White/ Brown,
- PackingCarton
- Carton Dimension41x41x24cm
- Packing Length(305±1.5)m
- Rip-CordYes
- Drain WireNo
- Sheath Physical PropertiesBefore Aging Tensile Strength (Mpa) ≥13.5, Elongation(%) ≥150,Aging Period(℃×hrs) 100℃×24h×7d,After Aging ,Tensile Strength(Mpa) ≥12.5, variance ratio:±25%, Elongation(%) ≥125, variance ratio:±20%,Cold bend(-20±2℃×4h) 8×Cable O.D.，No visible cracks,
- Electrical Characteristics (20℃)1.0-100.0MHz Impedance(Ω) 100±15,100 – 250MHz Impedance(Ω) 100±25,1.0-100.0MHz Delay Shew (ns/100m) ≤45,DC ResistanceΩ/100m) max 12,DC Conductor Resistance Unbalance(%) max 2,
- Conductor
- MaterialCCA（Copper content：27%）
- Nom.O.D.(Mm)0.585±0.01
- Insulation
- MaterialSolid HDPE
- Diameter1.05±0.05mm
- Sheath
- Thickness0.50±0.05 mm
- External O.D.6.0±0.30 mm
- SurfaceClean, Frap, Satiation
- MaterialFR-PVC(complies RoHS)
- ColorWhite RAL9003
- Surface Printing
- Letter Height2.5±0.2mm
- ColorBlack
- Print Error & Space≤±0.5%，1m
