TC-H6 6MP Color Maker WiFi Kamera

Rp799.000

KEY FEATURES

Plastic housing
Up to Panorama:3MP,2304×1296@15fps Detail:3MP,2304×1296@15fps
S+265/H.265/H.264B/H.264M/H.264H
Color:0.02Lux@(F1.6,AGC ON),B/W:0Lux with IR
IR range up to 50m
Built-in Mic, Built-in Speaker
Support microSD/microSDHC/microSDXC card,up to 512GB
Operating conditions -30℃~60℃(-22℉~140℉), ≤95%RH
DC12V±25%,Max. 13W
IP66

Categories: Tiandy, Wifi Kamera

Description
Reviews (0)

Specifications TC-H6 6MP Color Maker WiFi Kamera
Model	TC-H363N Spec: I5W/ WIFI/ Eu/ 4mm/ V4.0
Camera
Image Sensor	1/3″CMOS
Min. Illumination	Color: 0.02Lux@ (F1.6, AGC ON), B/W: 0Lux with IR
Shutter Time	1s to 1/100000s
Day & Night	IR-cut filter with auto switch
WDR	DWDR
S/N	>40dB
Angle Adjustment	(P)Fixed Lens: -60°~60°, Pan & Tilt Lens: 0~345°; (T)Fixed Lens: 5°-15°, Pan & Tilt Lens: -15~90°; (R)Fixed Lens: 0°, Pan & Tilt Lens: 0°
Lens
Lens Type	Fixed
Focal Length	4mm/ 4mm
Lens Mount	M12/ M12
Aperture Range	F1.6/F1.6, fixed focal lens
Field of View	(H) Fixed Lens:81.3°; Pan & Tilt Lens: 81.3° (V) Fixed Lens:44.4°; Pan & Tilt Lens: 44.4° (D) Fixed Lens:94.4°; Pan & Tilt Lens: 94.4°
DORI Distance	Fixed Lens: Detect: 59.26m; Observe: 23.52m; Recognize: 11.85m; Identify: 5.93m Pan & Tilt Lens: Detect: 59.26m; Observe: 23.52m; Recognize: 11.85m; Identify: 5.93m
Illuminator
IR LEDs	Panorama 4+ Detail 4
IR Distance	up to 50m
Wavelength	850nm
White LEDs	Panorama 4+ Detail 4
White light Distance	15m
Red and Blue Alarm Flash	Yes
Compression Standard
Video Compression	S+265/ H.265/ H.264B/ H.264M/ H.264H
Video Bit Rate	32k~4Mbps
Audio Compression	G.711A/G.711U
Audio Sampling Rate	8kHz/16kHz
Max. Resolution	Panorama: 3MP, 2304×1296 @15fps & Detail: 3MP, 2304×1296 @15fps
Main Stream	Panorama: PAL: 15fps (2304×1296, z1920x1080, 1280×720, 640×480, 704×576) NTSC: 15fps (2304×1296, 1920×1080, 1280×720, 640×480, 704×480)Detail: PAL:15fps (2304×1296, 1920×1080, 1280×720, 640×480, 704×576) NTSC:15fps (2304×1296, 1920×1080, 1280×720, 640×480, 704×480)
Sub Stream	Panorama: PAL: 15fps (704×576, 704×288, 640×360, 352×288) NTSC: 15fps (704×480, 704×240, 640×360, 352×240) Detail: PAL: 15fps (704×576, 704×288, 640×360, 352×288) NTSC: 15fps (704×480, 704×240, 640×360, 352×240)
BLC	Yes
HLC	Yes
AGC	Yes
3D DNR	Yes
White Balance	Auto/ Semi-auto/ Manual/ Sunny/ Natural light/ Warm light/ Sodium lamp/ Incandescent lamp/ Locked white balance
OSD	Overlay of additional characters in one area, 1 line, up to 48 characters or 16 Chinese characters; 1616/ 3232/ 48*48
Privacy Mask	4 black static areas
Defog	Yes
Feature
Alarm Trigger	Voltage Alarm; Disk Full; Disk R/W Error; IP Address Conflict
Auto-Tracking	Auto-Tracking
Linkage Method	rigger sound; trigger recording; trigger capture; notify surveillance center
Network
ANR	Yes
Protocols	HTTP; TCP/ IP; UDP; ICMP; DHCP; DNS; NTP; IPv4; SSH; Unicast; FTP
System Compatibility	P2P;CGI
Remote Connection	≤2
Client	Easy7 Smart Client
Mobile Client	EasyLive Plus
Web	IE10+; Firefox52+; Edge89+; Safari11+; Chrome57+
Wi-Fi
Transmission Distance	Up tp 50m( based on actual environment)
Wireless Standard	IEEE802.11b/ 802.11g/802.11n
Frequency Range	2.4 GHz ~ 2.4835 GHz
Channel Bandwidth	20/40MHz
Wi-Fi Security	WPA-PSK/WPA2-PSK
Interface
Communication Interface	1*RJ-45,10/100 Mbps self-adaptive Ethernet port
Built-In Mic	Yes
Built-In Speaker	Yes
Reset Button	Yes
On-board storage	Support micro SD / micro SDHC/ micro SDXC card, up to 512 GB
General
Web Client Language	3languages Simple Chinese/ English/ Vietnamese
Operating Temperature	-30℃~60℃(-22℉~140℉)
Operating Humidity	≤95%RH
Storage Temperature	-30℃~60℃(-22℉~140℉)
Storage Humidity	10%~95%RH(non-condensing)
Power Supply	DC12V±25%,Max. 13W
Protection	Surge2000V; zESD6000V; IP66
Boundary Dimensions	133(L) 102W) 209(H)mm
Package Dimensions	160(L) 160(W) 215(H)mm
Gross Weight	0.83kg
